•驗證Logix5550控制器和1756-CNB模塊是否處于工作狀態
插槽0和1，如圖所示。
•驗證1756-CNB模塊的節點地址為1，且節點
PLC-5C處理器的地址為11，如圖所示。
•驗證KTCX15驅動程序卡的配置是否如中所述
第2-3頁。
•驗證所有接線和布線是否正確連接。
使用以下命令配置網絡：
ControlNet的RSNetWorx
執行以下步驟來配置ControlNet網絡：
1.啟動ControlNet軟件的RSNetWorx• Verify that the Logix5550 controller and the 1756-CNB module are in slots 0 and 1 as shown. • Verify that the node address for the 1756-CNB module is 1 and the node address for the PLC-5C processor is 11 as shown. • Verify that the KTCX15 driver card is configured as described on page 2-3. • Verify that all wiring and cabling is properly connected. Configure the Network Using RSNetWorx for ControlNet Perform the following steps to configure the ControlNet network: 1. Start the RSNetWorx for ControlNet software
