8.選擇“優化并重新編寫所有連接的計劃”，然后單擊
好的。
9.關閉PLC-5 ControlNet配置窗口并小化
用于ControlNet軟件的RSNetWorx。
測試您現在已調試的ControlNet網絡的通信。你后的任務是
使用PLC-5C聯機測試通信。
1.啟動RSLogix5軟件。
2.從通訊菜單中，選擇系統通訊。
系統選項窗口將與系統一起出現
通訊選項卡打開。8. Select “Optimize and re-write schedule for all connections” and click on OK. 9. Close the PLC-5 ControlNet Configuration window and Minimize the RSNetWorx for ControlNet software. Test the Communications You now have the ControlNet network commissioned. Your last task is to go online with the PLC-5C to test the communications. 1. Start the RSLogix5 software. 2. From the Comms menu, select System Comms. The System Options window will appear with the System Communications tab open.
