每個ControlLogix機箱中的插槽0和1，如圖所示。
•驗證1756-CNB模塊的節點地址是否為1和6
展示。
•驗證KTCX15驅動程序卡的配置是否如中所述
第2-3頁。
•驗證所有接線和布線是否正確連接。
創建制作人
應用
執行以下步驟以創建producer應用程序。
1.打開RSLogix5000軟件。
2.從“文件”菜單中，選擇“新建”。新的控制器窗口將
顯得
• Verify that the Logix5550 controllers and the 1756-CNB modules are in slots 0 and 1 in each ControlLogix chassis, as shown. • Verify that the node addresses for the 1756-CNB modules are 1 and 6 as shown. • Verify that the KTCX15 driver card is configured as described on page 2-3. • Verify that all wiring and cabling is properly connected. Create the Producer Application Perform the following steps to create the producer application. 1. Open the RSLogix5000 software. 2. From the File menu, select New. The New Controller window will appear.
