重要提示：這些說明假設您已經安裝了
ControlLogix機箱和電源。如果你沒有
安裝了這些組件，現在按照
按照以下說明：
•ControlLogix機箱安裝說明，
出版物編號1756-5.2
•ControlLogix電源安裝說明，
出版物編號1756-5.1
1.在機箱中安裝1756-CNB模塊之前，請?jiān)O(shè)置模塊的
節點地址開關。
重要提示：必須為每個節點選擇一個01到99的節點地址
單元00無效。
對于示例應用程序，設置一個1756-CNB的節點地址
模塊至1，另一模塊至6。在后一個示例（1章）中，我們添加了
第三個模塊位于節點地址Important: These instructions assume that you have installed your ControlLogix chassis and power supplies. If you have not installed these components, install them now in accordance with the following instructions: • ControlLogix Chassis Installation Instructions, publication number 1756-5.2 • ControlLogix Power Supplies Installation Instructions, publication number 1756-5.1 1. Before installing a 1756-CNB module in its chassis, set the module’s node address switches. Important:You must select a unique node address of 01 to 99 for each module. 00 is invalid. For the example applications, set the node address of one 1756-CNB module to 1 and another to 6. In the last example (chapter 11), we added a third module at node address
